Dz H

Previous Model No: UADJ EHD

Revolutionary design combines slim visual width, low profile and hidden fixings. This heavy duty floor coverplate system is designed for use in polished concrete, roll-coat epoxy, tiles, vinyl and other floor finishes. Low profile and slender width allows for minimal substrate rebating. Leaves no visual grout line when applied to polish or trowel-finished concrete. Suitable for bulky-goods retail (ie Masters, Ikea) with rebating constraints. Stadiums, transit-centres, carparks and other buildings with suspended-slab concrete.



  • Concealed Fixings
  • Thermally Dynamic
  • High Capacity Low Maintenance
  • Bead blasted cover plate slip resistance classification V tested to AS4586 2013

Compatible Finishes

  • Tiles
  • Vinyl
  • Epoxy
  • Exposed Concrete

Standard Finish




Cover Plates


Cover Plate Options
